Cab

​

Protection against bad weather for machine operator, fast assembly and disassembly, light.

​

  • FRONT panel composed of a metal structure, a curved tempered glass thickness 5mm heating resistor

  • Single folded sheet metal roof with skai-type under-roof cladding

  • REAR panel in folded sheet metal with a 5mm thick polycarbonate window

  • Equipment: windscreen wiper motor 12V, windscreen washer, ceiling light, 2 front work lights, front and rear sun visors, 12V socket

  • Set of flexible doors: easily removable by zip

  • Dimensions: interior height 1m85, interior width 1m

  • Weight: 120 kg

Cabine

Transport trailer ​

​

Special Easy-Grader grader trailer: ​

  • Integral multiplex wood table top

  • Wheels: under floor

  • 3 axles

  • Tire: 195 / 55R10

  • 2 ramps with attachment to the rear profile of the platform, storage under the floor ​

  • Accessories: Tool box; 4 tensioners and lashing straps

  • Dimensions: floor length: 5000 mm; floor width: 2040 mm

  • Weight: 880 kg (empty) and 3500 kg (PTAC)

Balai

Front brush​​

​

  • Mixed polyester/polypropylene brush

  • Length: 1600 mm

  • Diameter: 550 mm

  • Mechanical offset 300mm to the right and left

  • 2 tyre wheels Ø 200 mm puncture-proof

  • Hydraulic right and left orientation by 2 cylinders

  • Hydraulic drive by 1 motor

  • Parallelogram suspension with floating hydraulic line


2D double mast laser guidance
TOPCON

​

2D guidance system including:

  • Double masts with laser cells

  • Tilt sensor

  • Ultrasonic probe

Guidage laser 2D double MAT

2D double mast laser guidance
TRIMBLE

​

2D guidance system including:

  • Double masts with laser cells

  • Tilt sensor

  • Ultrasonic probe


2D double mast laser guidance
MOBA

​

2D guidance system including:

  • Double masts with laser cells

  • Tilt sensor

  • Ultrasonic probe


Ripper teeth for front blade

​

In addition to the front blade, you can add ripper teeth to it.

Ripper teeth
Dents de ripper lame avant
graissage automatique

Automatic greasing

​

We propose to integrate into the Easy-Grader this equipemt that allows centralised greasing management (supplied by Hydrokit.)

Centralized lubrication
camera

Reversing camera

​

7" monitor + reversing camera + 20m 12/24 Vdc cable
Customs nomenclature: 84310000

Reversing camera

Pedestrian detection camera

​

  • Safety: detects only pedestrians in the environment: personal safety.

  • Efficiency: warns the driver of moving machinery in the zone of movement.

  • Customizable: detection zones are all configurable via wifi.

  • Extreme conditions: works day and night.



Includes:

  • 7" screen

  • Artificial intelligence camera

  • Screen support

  • Connecting cables to suit machine

Pedestrian detection camera

360° pedestrian camera

​

A complete 360° vision camera kit with monitor, 4 wide-angle pedestrian detection cameras, 2D/3D management module.


How it works:
This kit creates a panoramic image around your equipment.

When a pedestrian is detected, we focus (full-screen image) on the detection side
This vision can be activated when reverse gear is activated, or as soon as the equipment is switched on.
You can record images using 2 SD card slots (limited to 128GB per solt and card not supplied).



Kit contents :

  • 7" Full HD monitor

  • 4 IP69K, full HD cameras with pedestrian detection.

  • A module to build the 2D and 3D image of the 360° vision around the equipment.

  • Cables and extension leads...

  • A camera calibration tool

360° pedestrian camera
360° pedestrian camera

Reversing radar

​

Manoeuvre in complete safety

Reversing radar

Lynx reversing alarm

​

Inform nearby pedestrians that the machine is in motion

Lynx reversing alarm
